Multi-GPU Support
WS X299 Sage fits up to four dual-slot graphics cards and supports both NVIDIA® SLI™ and AMD CrossFireX™ 4-way configurations to enable multi-GPU setups that harness the full power of the latest graphics technologies, including NVIDIA® Quadro®. With performance beyond 15.23 TFLOPS, NVIDIA Quadro is the perfect complement to WS X299 Sage, delivering the best performance for design, modeling, medical research, and processing-intensive simulation and rendering applications.
5-Way Optimization
ASUS 5-Way Optimization makes your workstation smart. One click takes care of complex tuning, dynamically optimizing essential aspects of the system to provide overclocking and cooling profiles that are tailored for your rig.
- An automated tuning utility that optimizes overclocking and cooling profiles for your unique system configuration.
- Fans stay whisper-quiet with everyday computing, and deliver optimal airflow when the system is crunching through CPU or GPU-intensive tasks.
- Stress test function helps optimize and overclock for CPU- or memory-centric workloads.
- Complete IT Infrastructure Management with ASMB9 Out-of-band remote management and In-band ASUS Control Center providing a complete server management solution reducing IT operating costs with features like remote BIOS updating, monitoring multiple systems via mobile device, and one-click software updates/dispatching.
- 5-Way Optimization featuring Auto-Tuning and FanXpert 4 delivers automatic overclocking profiles for maximum OC performance while headers for thermal sensors, AIO pump, and watercooling provide dynamic system cooling
- 7x PCIe X16 Slots with Patent-pending SafeSlot feature an injection molding process that integrates metal framing for stronger, firmly anchored PCIe slots built for heavyweight GPUs, ideal for supporting 4-Way NVIDIA®SLI® or AMD® CrossfireX™
- OC Design featuring ASUS ProClock and T-Topology Technology extends CPU and Memory overclocking margins while providing the flexibility to extract every ounce of performance for memory speeds of DDR4-4200 MHz and beyond
- Designed for 7th generation LGA2066 socket Intel® Core™ X-Series processors with dual M.2 and U.2, front panel USB 3.1 Gen2, Dual Gigabit Intel® LAN, support for Thunderbolt 3, Intel® VROC and Intel® Optane™ Memory compatibility
| Brand | |
|---|---|
| Brand | ASUS Computer International |
| CPU / Processor | |
|---|---|
| Processor Supported | Core X-Series |
| Total Processor Supported | 1 |
| Processor Socket | Socket R4 LGA-2066 |
| GPU / Graphics | |
|---|---|
| Multi GPU Supported | SLI |
| Onboard Video | No |
| Memory / RAM | |
|---|---|
| Memory Technology | DDR4 SDRAM |
| Memory Speed Supported | 2133 MHz |
| Memory Form Factor | DIMM |
| Number of Memory Slots | 8 |
| Maximum Memory Supported | 128 GB |
| Storage | |
|---|---|
| Intel VROC | Yes |
| Intel RSTe | Yes |
| RAID Supported | Yes |
| Intel Optane Memory Ready | Yes |
| RAID Levels | 0 |
| USB Ports | |
|---|---|
| Total Number of Onboard USB P | 3 |
| Number of Onboard USB 3.1 Por | 3 |
| Total Number of USB Ports | 12 |
| Number of USB 2.0 Ports | 4 |
| Number of USB 3.1 Ports | 7 |
| Ethernet Port | |
|---|---|
| Number of Network (RJ-45) Por | 2 |
| Gigabit Ethernet | Yes |
| Audio Ports | |
|---|---|
| S/PDIF | Yes |
| Audio | |
|---|---|
| Audio Channels | 7.1 |
| Size / Dimensions | |
|---|---|
| Form Factor | SSI CEB |
| General Features | |
|---|---|
| Chipset Manufacturer | Intel |
| Chipset Model | X299 |
| Controller Type | Serial ATA/600 |
| Manufacturer | ASUS Computer International |
| Expansion Slots | |
|---|---|
| Number of PCI Express x16 Slo | 7 |
| Total Number of PCI Express S | 7 |
| Total Number of Expansion Slots | 7 |
| Misc Ports | |
|---|---|
| Number of M.2 Interfaces | 2 |
| Number of SATA Interfaces | 8 |
| Compliance & Certification | |
|---|---|
| Environmentally Friendly | Yes |
