The Club 3D CSV-1563 USB Gen2(10G) Type-C Triple 4K60Hz Display(HDMI™/ DP™) Docking Station PD Charging is designed for extra connectivity demands. With the USB Type-C Docking station, you can extend the connection of a computer to more USB peripherals, Ethernet network, the speaker and the microphone via USB Type-C interface. Feel free to plug in upside down for USB Type-C plug is reversible. Adopting PD Charging technology, upstream charging function through USB Type-C interface, you can charge the host station(Laptop) up to 96W. With the built-in USB Gen1 (5Gbps) ports, the docking station enables you to enjoy the super speed data transmission between USB peripherals. In addition, the docking station is equipped with three display video outputs, HDMI™ and/or DisplayPort™ up to a maximum of 3840 x 2160 @ 60Hz each. With triple 4K60Hz Ultra HD display simultaneously, the docking station allows you to split up the content to triple 4K60Hz display devices with the latest DisplayLink driver installed. Enhanced expansion capability, this docking station with video is the most versatile accessory that also complements your home or office space.
Features:
- Designed for DP 1.4 Alternate Mode supported Type C and Thunderbolt 3 Hosts
- Video capability: Triple 4K60Hz via 3x DP™/HDMI™
- DisplayLink™ DL-6950 chip inside
- USB Type-C host connection supports power delivery(PD) up to 96W
- 4x USB Type-A and 1x USB Type-C downstream ports for abundant connections of USB peripherals
- USB Type-C(Downstream) also supports BC 1.2 & Apple charge) up to 20W
- 1Gbps Ethernet RJ-45 provides reliable wired network
- SD4.0 card reader transfers files at fast speed
- Separate audio output and microphone input
- LED indication when power on
- Vertical installation takes up less space on the desk
- Compatible with Win/Chrome/Mac/M1 chip
- Wired connectivity technology provides a high-powered and dependable connection
- USB Type C host interface allows powerful and efficient transfer of data with maximum productivity
- Desktop PC device supported according to your requirements with maximum productivity
- 1.25 GB/s maximum data transfer rate for convenient, quicker exchange of data and information
- Gigabit Ethernet Ethernet technology for increasing efficiency with the quicker transfer and sharing of information
- Power Adapter power source type for your docking station better reliance and maximum energy dependability
- The HDMI supports digital audio/video output to a wide assortment of HD gadgets
- 6 USB ports offers a more refined structure and safer to use connectivity
- 1 Network (RJ-45) Ports conveniently allows Ethernet cables to transmit data and power instantaneously using a single network cable
| Brand | |
|---|---|
| Brand | Club 3D |
| GPU / Graphics | |
|---|---|
| Number of Displays Supported | 3 |
| Screen / Display | |
|---|---|
| Screen Mode Supported | 4K |
| Supported Resolutions | 3840 x 2160 |
| Power & Battery | |
|---|---|
| Maximum Power Supply Wattage | 130 W |
| Power Source Type | Power Adapter |
| Networking & Connectivity | |
|---|---|
| Connectivity Technology | Wired |
| USB Ports | |
|---|---|
| Number of USB 3.2 Gen 1 Type- | 4 |
| USB Power Delivery | 96W |
| Total Number of USB Ports | 6 |
| USB Type-C | Yes |
| Number of USB Type-C Ports | 2 |
| USB Type-A | Yes |
| Number of USB Type-A Ports | 4 |
| HDMI Ports | |
|---|---|
| HDMI | Yes |
| Number of HDMI Ports | 3 |
| DisplayPort | |
|---|---|
| DisplayPort | Yes |
| Number of DisplayPorts | 3 |
| DisplayPort Version | 1.2 |
| Ethernet Port | |
|---|---|
| Number of Network (RJ-45) Por | 1 |
| Network (RJ-45) | Yes |
| Number of RJ-45 Ports | 1 |
| Audio Ports | |
|---|---|
| Audio Line Out | Yes |
| Audio Line In | Yes |
| Card Reader | |
|---|---|
| Memory Card Reader | Yes |
| Memory Card Supported | SD |
| General Features | |
|---|---|
| Maximum Data Transfer Rate | 1.25 GB/s |
| Manufacturer | Club 3D |
| Brand Compatibility | Apple |
| Misc Ports | |
|---|---|
| Host Interface | USB Type C |
| Brand | Club 3D |
| MPN | CSV-1563 |
| Unit Count | 1 Units |
