The Cat6 Snagless Unshielded (UTP) Slim Network Patch Cable is the perfect solution for high density datacenter applications. The use of 28 AWG conductors allows for a 36% reduction in diameter over a standard Cat6 network patch cable. This reduced diameter provides a smaller cable surface area which allows for increased airflow when compared to standard Cat6 cables. The 28 AWG conductors also allow this cable to have a smaller bend radius than standard Cat6 cables. The small size and small bend radius of this cable allows it to be easily routed through cable management panels.
This cable is designed for fast Ethernet networks that require bandwidth-intensive voice, data, or video distribution applications. Constructed from high quality copper cable, this design minimizes Near-End Crosstalk (NEXT) levels. The molded, snagless boot prevents unwanted cable snags during installation and provides extra strain relief. Available in a variety of colors to easily color-code your network installation.
This patch cable does not meet the recommend conductor size, 22-26AWG, requirement of ANSI/TIA-568-C.2. Attenuation is increased due to the smaller 28AWG conductors.
- 36% reduction in diameter compared to standard Cat5e cables
- Meets the ANSI/TIA-568-C.2 standard for Patch Cord Performance
- Snagless connector design28AWG construction
- Connector 1: (1) RJ-45 Male
- Connector 2: (1) RJ-45 Male
- Lifetime Warranty
| Brand | |
|---|---|
| Brand | Legrand Group |
| Appearance | |
|---|---|
| Boot Type | Snagless |
| General Features | |
|---|---|
| Data Transfer Rate | 10 Gbit/s |
| Manufacturer | Legrand Group |
| Cables | |
|---|---|
| Cable Shielding Type | Unshielded Twisted Pair (UTP) |
| Cable Length | 8" |
| Cable Type | Category 6 |
| Cable Characteristic | Patch Cable |
| Connector Type on First End | RJ-45 Network - Male |
| Connector on First End Details | 1 x RJ-45 Network - Male |
| Connector Gender on First End | Male |
| Connector Type on Second End | RJ-45 Network - Male |
| Connector on Second End Details | 1 x RJ-45 Network - Male |
| Connector Gender on Second End | Male |
| Connector Plating | Gold |
| Connector Material | Gold |
| Jacket Material | Polyvinyl Chloride (PVC) |
| Jacket Type | Standard Non-rated |
| Shielding | No |
| American Wire Gauge | 28 AWG |
| Number of Pairs | 4 |
| Number of Conductors | 8 |
| Insulation Material | FM-PE |
| Brand | Legrand Group |
| UPC/GTIN | 757120022121 |
| MPN | C2G02212 |
| Unit Count | 1 Units |
| Warranty | Lifetime |
