Electrical Characteristics
Conductor DC Resistance - 9.38
100m (maximum)
Impedance - 100
Capacitance - 5600pf/100m
Propagation Delay - 545ns/100m (maximum)
Delay Skew - 45ns/100m (maximum)
Physical Characteristics
Wiring Scheme - T568B
Standard: Category 6 TIA/EIA-568-B-2.1, draft 9
Connector: 50 micron gold-plated RJ45
Temperature Rating - 60°C
Voltage Rating - 30V
Approvals - RoHS Compliant
Warranty - Lifetime
Package Type - Polybag
Conductor (Qty. 4 twisted pair)
Conductor Type - 24AWG (7/0.20), Stranded Bare Copper
Insulation - H-D PE
Diameter - 0.98 ± 0.05mm
Colors - Blue, Blue-White, Orange, Orange-White, Green, Green-White, Brown, Brown-White
Connector Type (Qty. 2)
Connector Type - 8P8C (RJ45)
Gender - Male
Connector Material - Polycarbonate
Contact Material - Copper Alloy, Gold Plating - 50µm
Hood Material - Molded PVC
Overall Cable
Jacket - PVC
Minimum Average Thickness - 0.60mm
Outer Diameter - 6.20 ± 0.30mm
- Provides a simple and efficient way to connect multiple devices within your business network, ensuring smooth communication and reliable data transfer
- Features Category 6 cable type engineered for stable performance and optimized connectivity across multiple supported devices
- Gold connector plating delivers a refined finish while ensuring smooth performance and reliable connectivity across supported devices
- Molded feature enhances usability and operational efficiency, providing reliable performance and simplifying everyday connectivity tasks
- RJ-45 Network - Male delivers stable signal routing to network devices for uninterrupted communication and system integration
| Brand | |
|---|---|
| Brand | Legrand Group |
| General Features | |
|---|---|
| Manufacturer | Legrand Group |
| Cables | |
|---|---|
| Cable Shielding Type | Unshielded Twisted Pair (UTP) |
| Conductor | Copper |
| Cable Length | 1 ft |
| Cable Type | Category 6 |
| Cable Characteristic | Patch Cable |
| Connector Type on First End | RJ-45 Network - Male |
| Connector on First End Details | 1 x RJ-45 Network - Male |
| Connector Gender on First End | Male |
| Connector Type on Second End | RJ-45 Network - Male |
| Connector on Second End Details | 1 x RJ-45 Network - Male |
| Connector Gender on Second End | Male |
| Contact Plating | Gold |
| Connector Plating | Gold |
| Contact Material | Copper Alloy |
| Connector Material | Polycarbonate |
| Jacket Material | Polyvinyl Chloride (PVC) |
| Shielding | No |
| American Wire Gauge | 24 AWG |
| Number of Pairs | 4 |
| Number of Conductors | 8 |
| Insulation Material | High-density Polyethylene (HDPE) |
