Extend lossless HD video
KVM Extender DL DVI USB transmits lossless DVI video up to 160 feet, enabling workstations to be put in quiet, climate controlled areas while CPUs are housed separately and securely. Lossless video ensure a high image quality, without delay or visible artifacts.
Use CATx cable
These extenders use a single CATx cable for dual-link DVI, USB 2.0, and analog audio, so they integrate directly and easily into your infrastructure. The extender set is plug-and-play, with no need for configuration or software downloads.
USB 2.0
USB support is for low-speed and full-speed USB devices, from keyboards, mouse, and touchscreen monitors, to graphics tablets and mass storage devices.
EDID management
The extender system features intelligent EDID management so that the true data characteristics of the monitor are shared with the computer.
- Audio
- CATx connections
- Transmit dual-link DVI, USB 2.0, and analog audio over a single CAT7 or CAT6a cable, up to 160 feet (50 m).
- DL DVI-D Video Resolution 1920 x 1200 @60Hz
- USB 2.0 - transparent
| Brand | |
|---|---|
| Brand | Black Box Corporation |
| Power & Battery | |
|---|---|
| Input Voltage Range | 120V AC to 230V AC |
| Input Voltage | 240 V AC |
| Networking & Connectivity | |
|---|---|
| Connectivity Technology | Wired |
| USB Ports | |
|---|---|
| USB | Yes |
| Number of USB Ports | 5 |
| Ethernet Port | |
|---|---|
| Number of Network (RJ-45) Por | 2 |
| Network (RJ-45) | Yes |
| Audio Ports | |
|---|---|
| Headphone | Yes |
| Camera / Webcam | |
|---|---|
| Maximum Video Resolution | 2560 x 1600 |
| Size / Dimensions | |
|---|---|
| Transmitter Weight (Approxima | 11.20 oz |
| Receiver Width | 4.66" |
| Receiver Weight (Approximate) | 11.20 oz |
| Receiver Height | 1.02" |
| Receiver Depth | 2.94" |
| Transmitter Depth | 2.94" |
| Transmitter Height | 1.02" |
| Transmitter Width | 4.66" |
| General Features | |
|---|---|
| Maximum Operating Distance | 164.04 ft |
| Manufacturer | Black Box Corporation |
| Number of Computers Supported | 1 |
| Video Ports | |
|---|---|
| DVI | Yes |
| Number of DVI Ports | 2 |
| Compliance & Certification | |
|---|---|
| TAA Compliant | Yes |
| Miscellaneous | |
|---|---|
| Product Name | Wizard SRX ACU5520A KVM Console/Extender |
