Scalable HD Video Distribution Over Your Existing IP Network
The MediaCento IPX HD is a robust and flexible solution for distributing High Definition (1080p) HDMI video and audio over your existing, standards-based Gigabit Ethernet network using TCP/IP protocols. Its primary benefit is enabling scalable video extension in applications like digital signage, corporate training, classroom streaming, and control room video sharing. It supports both basic point-to-point and large-scale point-to-multipoint configurations, utilizing a multicast setup where one transmitter can drive many receivers without placing extra burden on the network.
Simplified Setup
Setup is significantly simplified by its plug-and-play nature and its PoE power support, which eliminates the need for separate external power supplies. The system ensures excellent picture quality with 1080p HD resolution, an EDID copy function for optimal PC-to-screen performance, and is HDCP 2.2 compliant. It also allows for the creation of video walls up to 8x8 displays and extends signals far beyond the standard 328 feet (100 m) point-to-point distance when network switches are introduced.
- Maximum latency 2 frames or 33ms
- PoE power eliminates external power supplies
- Use with the MediaCento Controller for matrix switching and video wall control
- Create eye-catching video walls of up to 8x8 displays
- Any source to any screen, over IP
- Extend HDMI video signals over a Gigabit Ethernet network
- Intercompatible with the MediaCento 4k
- Setup units using only the front panel interface, no additional configuration required
- Supports up to 1080p HD
| Brand | |
|---|---|
| Brand | Black Box Corporation |
| GPU / Graphics | |
|---|---|
| Graphics Modes | Full HD |
| Networking & Connectivity | |
|---|---|
| Connectivity Technology | Wired |
| HDMI Ports | |
|---|---|
| HDMI In | Yes |
| Number of HDMI Inputs | 1 |
| Ethernet Port | |
|---|---|
| Number of Network (RJ-45) Por | 1 |
| Network (RJ-45) | Yes |
| Number of Network (RJ-45) Ports | 1 |
| Camera / Webcam | |
|---|---|
| Maximum Video Resolution | 1920 x 1080 |
| Input Devices | |
|---|---|
| Number of Input Devices Suppo | 1 |
| Size / Dimensions | |
|---|---|
| Transmitter Weight (Approxima | 1.04 lb |
| Transmitter Depth | 3.86" |
| Transmitter Weight (Approximate) | 1.04 lb |
| Transmitter Height | 1.26" |
| Transmitter Width | 7.09" |
| General Features | |
|---|---|
| Maximum Operating Distance | 328.08 ft |
| Manufacturer | Black Box Corporation |
| Number of Input Devices Supported | 1 |
| Printer/Scanner/Fax Specs | |
|---|---|
| Media Type Supported | Twisted Pair |
| Compliance & Certification | |
|---|---|
| TAA Compliant | Yes |
| Environmentally Friendly | Yes |
