- Autosenses speeds up to 115.2 kbps.
- Works as a standalone or hot-swappable chassis-based extender.
- Easy to install.
- Includes a power supply. Or you can power multiple units with the space-saving 19" rackmountable FlexPoint Power Chassis.
- Features DTE/DCE configuration for easy connections to DTE or DCE devices using straight-through cabling.
- Supports half- and full-duplex.
- Remote loop capability for remote fiber testing and LEDs for status monitoring.
Extend async RS232 devices beyond the 50 ft limitation using single-mode fiber cables at data rates up to 115.2 kbps and reach distances of 18.6 MI. (30KM). Serial extenders work well in factory automation, building automation, and process automation where PLC's with RS232 interfaces are used to control devices. The ability to extend the distance to their devices over single-mode fiber while also adding protection from electrical interference, which can be caused by large motors, which are prevalent in these environments, is very beneficial.
- Remote loop capability for remote fiber testing and LEDs for status monitoring.
- DCE/DTE switch for easy direct connection no special cables needed.
- Data rate up to 115.2 kbps
- Range of up to 30KM (18.6 MI.) at 115.2 kbps over MM fiber
- Full duplex operation over SM fiber
| Brand | |
|---|---|
| Brand | Black Box Corporation |
| Power & Battery | |
|---|---|
| Power Source | Power Supply |
| USB Ports | |
|---|---|
| USB | No |
| Ethernet Port | |
|---|---|
| Network (RJ-45) | No |
| Audio | |
|---|---|
| Digital Audio | No |
| Size / Dimensions | |
|---|---|
| Form Factor | DIN Rail Mountable |
| General Features | |
|---|---|
| Digital Audio/Video | No |
| Maximum Distance Supported | 28 km |
| Manufacturer | Black Box Corporation |
| Video Ports | |
|---|---|
| DVI | No |
| Misc Ports | |
|---|---|
| Management Port | No |
| Total Number of Ports | 2 |
| Number of Serial Ports | 1 |
| Parallel Port | No |
| Number of SC Ports | 1 |
| Printer/Scanner/Fax Specs | |
|---|---|
| Media Type Supported | Optical Fiber |
| Cables | |
|---|---|
| Fiber Optic Cable Core/Claddi | 9/125 µm |
| Fiber Mode Supported | Single-mode |
| Fiber Optic Cable Wavelength | 1310 nm |
| Compliance & Certification | |
|---|---|
| TAA Compliant | Yes |
| Environmentally Friendly | Yes |
