The DKM FX Modular KVM Extender Interface Card extends visually lossless, high-resolution DisplayPort signals over CATx cable. It also features two USB HID ports so you can easily connect your keyboards, mice, and other devices. You can use the extender card with the DKM FX Chassis for matrix switching or as a point-to-point KVM extender.
The DKM FX Extender Card supports 4K resolutions (4096 x 2160 and 3840 x 2160) in single-head mode and up to 1920 x 1200 video in dual-head mode. Audio is directly reproduced by any connected displays with integrated speakers. The stereo signal can also be extracted and output separately.
- Dual-Head DP video with resolutions up to 1920 x 1080 on each video head
- Single-head DP video with resolutions up to 3840 x 2160
- Support for USB HID keyboards and mice
- Intelligent EDID management
- Compatible with Windows, Linux, Mac, and other common operating systems
- Supports embedded audio on DP connector (with compatible extender)
- Embedded audio supported on DP connector (with compatible endpoint)
| Brand | |
|---|---|
| Brand | Black Box Corporation |
| GPU / Graphics | |
|---|---|
| Graphic Mode | 4K |
| Networking & Connectivity | |
|---|---|
| Connectivity Technology | Wired |
| USB Ports | |
|---|---|
| USB | Yes |
| Number of USB Ports | 3 |
| DisplayPort | |
|---|---|
| DisplayPort | Yes |
| Camera / Webcam | |
|---|---|
| Maximum Video Resolution | 4096 x 2160 |
| Size / Dimensions | |
|---|---|
| Receiver Width | 5" |
| Receiver Weight (Approximate) | 9.60 oz |
| Receiver Height | 0.70" |
| Receiver Depth | 5.75" |
| General Features | |
|---|---|
| Manufacturer | Black Box Corporation |
| Device Type | KVM Extender |
Black Box DKM Modular KVM Extender - Fiber Optic, 4K30 DisplayPort 1.1 - 4K - 4096 x 2160 Maximum Video Resolution - 3 x USB - DisplayPort - For Mac, Sun, Linux, Unix, Windows
