- Supports NTSC, PAL, and SECAM video.
- For color video over CAT5, the balun supports 2200-foot (670.5-m) distances.
Running multiple cables for your CCTV cameras and other devices? Extend your links while using inexpensive UTP cable instead of coax wiring with this balun.
This balun has RJ-45 connectors and transmits video plus power over a single 4-pair CAT3 or CAT5 cable. It supports baseband, NTSC, PAL, or SECAM video at up to 2500 feet (762 m), plus it supports 24-VAC power at up to 518 feet (157.8 m) when using 5 VA.
The balun works with the CCTV Passive Hubs (IC562A - IC563A).
- Extend your links while using inexpensive UTP cable instead of coax wiring.
- Supports NTSC, PAL, and SECAM video.
- For color video over CAT5, the balun supports 670.5m distances.
- Replace your bulky coax video cables with lightweight CAT5 cabling.
- Send video plus remote power.
| Brand | |
|---|---|
| Brand | Black Box Corporation |
| Ethernet Port | |
|---|---|
| Number of Network (RJ-45) Por | 1 |
| Network (RJ-45) | Yes |
| Size / Dimensions | |
|---|---|
| Diameter | 1" |
| General Features | |
|---|---|
| Maximum Operating Distance | 2500 ft |
| Manufacturer | Black Box Corporation |
| Compliance & Certification | |
|---|---|
| TAA Compliant | Yes |
| Environmentally Friendly | Yes |
Black Box CCTV Power-Through Balun with RJ-45 Connectors - 2500 ft Maximum Operating Distance - Network (RJ-45) - TAA Compliant
