The Agility IP-Based KVM Extension system transmits DVI video, USB, and audio signals via an Ethernet local area network (LAN). Send signals up to 330 feet (100 m), or even farther with the addition of network switches. Use the Agility Controller (ACR1000-CTL-24) to enable remote secure configuration of transmitters and receivers via a Web browser.
The Agility system offers a flexible topology of switching and extension. Use it in point-to-point KVM extension, to multicast HD video, or for single-target sharing. Agility transmits pixel-perfect video with no-loss compression, minimizing bandwidth use while maximizing user experience. Maximum resolution is 1920x1080.
- Data cyncryption via 128-bit AES.
- Magic Eye support to handle dithered video graphics.
- Supports a second LAN port to switch signals together (Teaming Mode), which increases bandwidth.
- Scalable high performance IP-Based KVM Extender and KVM Matrix system.
- Maximum resolution is 1920x1080.
- No-loss compression minimizes bandwidth use while maximizing the user experience.
- Delivers perfect digital video with no loss.
| Brand | |
|---|---|
| Brand | Black Box Corporation |
| GPU / Graphics | |
|---|---|
| Graphic Mode | Full HD |
| Networking & Connectivity | |
|---|---|
| Connectivity Technology | Wired |
| USB Ports | |
|---|---|
| USB | Yes |
| Number of USB Ports | 1 |
| Ethernet Port | |
|---|---|
| Number of Network (RJ-45) Por | 2 |
| Network (RJ-45) | Yes |
| Audio Ports | |
|---|---|
| Headphone | Yes |
| Camera / Webcam | |
|---|---|
| Maximum Video Resolution | 1920 x 1080 |
| Audio | |
|---|---|
| Microphone | Yes |
| Size / Dimensions | |
|---|---|
| Transmitter Weight (Approxima | 1.76 lb |
| Transmitter Depth | 4.80" |
| Transmitter Height | 1.76" |
| Transmitter Width | 7.92" |
| General Features | |
|---|---|
| Maximum Operating Distance | 330 ft |
| Manufacturer | Black Box Corporation |
| Device Type | KVM Extender |
| Number of Computers Supported | 2 |
| Video Ports | |
|---|---|
| DVI | Yes |
| Number of DVI Ports | 2 |
| Compliance & Certification | |
|---|---|
| TAA Compliant | Yes |
| Environmentally Friendly | Yes |
Black Box Agility KVM-Over-IP Matrix, Dual-Head DVI-D, USB 2.0, KVM Transmitter - 2 Computer(s) - 330 ft Range - Full HD - 1920 x 1080 Maximum Video Resolution - 2 x Network (RJ-45) - 1 x USB - 2 x DVI - TAA Compliant
