Mass storage and flexibility in 2U and additional OS Kernal Disk
RS520-E8-RS12-E V2 is equipped with 12 SAS/SATA 3.5-inch disk drive bays. The hot-swappable design provides non-stop high availability, making short work of maintenance. RS520-E8-RS12-E V2 also offers great freedom when it comes to the choice of operating system drive type and placement, with M.2 slot available, and two hot-swappable 2.5-inch SSD bays.
- Barebone System is compact, stylish, space-efficient, and portable, ideal for daily office and home use
- Windows Server 2012 R2 OS support includes creative and productive tools you need for smooth workflows
- Intel Xeon processor provides high performance, built-in security, and remote management for enterprise systems
- With Serial ATA/600 interface, experience high-speed data transfer and robust reliability for optimized system performance
- Rack-mountable barebone system ensures clutter-free, organized setups with improved accessibility and efficiency
- Featuring 4 USB ports to connect USB-compatible devices for enhanced flexibility and convenience
- Gigabit Ethernet port supports ultra-fast network speeds for smooth data transfer and improved system performance
- DDR4 SDRAM slot reduces processor idle time, improving multitasking and overall computing speed
| Brand | |
|---|---|
| Brand | ASUS Computer International |
| CPU / Processor | |
|---|---|
| Processor Supported | Xeon |
| Number of Processors Supported | 2 |
| 64-bit Processing | Yes |
| Processor Socket | Socket LGA 2011-v3 |
| GPU / Graphics | |
|---|---|
| Graphics Memory Capacity | 32 MB |
| Memory / RAM | |
|---|---|
| Memory Technology | DDR4 SDRAM |
| Memory Standard | DDR4-2133/PC4-17000 |
| Total Number of Memory Slots | 16 |
| Maximum Memory Supported | 1 TB |
| Storage | |
|---|---|
| RAID Supported | Yes |
| Power & Battery | |
|---|---|
| Number of Power Supplies Inst | 2 |
| Input Voltage | 230 V AC |
| Maximum Power Supply Wattage | 770 W |
| USB Ports | |
|---|---|
| Total Number of USB Ports | 4 |
| Number of USB 3.0 Ports | 2 |
| Size / Dimensions | |
|---|---|
| Form Factor | Rack-mountable |
| Rack Height | 2U |
| General Features | |
|---|---|
| Chipset Manufacturer | Intel |
| Chipset Model | C612 |
| Controller Type | Serial ATA/600 |
| Manufacturer | ASUS Computer International |
| Expansion Slots | |
|---|---|
| Number of PCI Express x16 Slo | 1 |
| Number of PCI Express x8 Slots | 3 |
| Total Number of Expansion Slots | 4 |
| Drive Bays | |
|---|---|
| Number of Total Expansion Bays | 14 |
| Number of 3.5" Bays | 12 |
| Misc Ports | |
|---|---|
| Number of SATA Interfaces | 9 |
| Compliance & Certification | |
|---|---|
| Environmentally Friendly | Yes |
