IMPROVED COOLING PERFORMANCE BY NEW PRODUCTION PROCESS
The high thermal conductivity of aluminum is fully retained by a new type of extrusion. This new production process creates a powerful yet very compact radial heat sink. The particularly thin cooling fins of the new Alpine are fanned out in a Y-shape. This increases the surface area of the heat sink and therefore the cooling capacity.
WIDE RPM RANGE
The Alpine 23 features a new motor technology with a very wide, PWM-controlled RPM range. This keeps the noise level at a minimum while guaranteeing maximum cooling performance when needed.
LOWER POWER CONSUMPTION & MINIMUM VIBRATION
The new Alpine 23 is powered by an updated motor and runs much more efficiently than its predecessors. Due to sinus-magnetizing the new motor creates just 5 % of the vibration from commutation of a regular DC-motor. These factors contribute towards saving energy, lowering the coil temperature and reducing vibrations to a minimum without compromising performance.
HIGH QUALITY BEARING
Thanks to an alloy/lubricant combination developed in Germany, friction within the bearing is reduced and greater efficiency is achieved. As a result, there is less heat development as well as less bearing noise, which means you can enjoy a longer service life from your fan.
EXTENDED LIFE SPAN
A 10 °C lower motor temperature roughly doubles the life span of a fan. The new ARCTIC motor has a four times longer service life through its low coil temperature.
PRE-APPLIED MX-2 THERMAL PASTE
The pre-applied, high-performance MX-2 thermal compound ensures fast and clean installation.
EASY AND TOOL-FREE INSTALLATION
Thanks to the mounting clips, the installation is really easy. Alpine 23 is simply plugged onto the existing AMD retention modules and screwed tight.
- Up to 2000 rpm fan speed and heavy-duty shroud ensure safe and effective cooling
- Features fluid dynamic bearing to improve longevity, silence, and stability
- The competent cooling system is specially designed for standard processors
| Brand | |
|---|---|
| Brand | Arctic Cooling |
| CPU / Processor | |
|---|---|
| Compatible AMD Socket | FM1 |
| Size / Dimensions | |
|---|---|
| Maximum Fan Diameter | 3.54" |
| General Features | |
|---|---|
| Heatsink Material | Aluminum |
| Manufacturer | Arctic Cooling |
| Fan Bearing Type | Fluid Dynamic Bearing |
| Fan Speed (Max) | 2000 rpm |
| Number of Fans | 1 |
| Cables | |
|---|---|
| Connectors | 4-Pin |
| Compliance & Certification | |
|---|---|
| Noise Levels (A-Weighted) | 35.8 dB(A) |
