- Compliant QSFP MSA specifications
- Fully compatible with IEEE802.3ba and Infiniband QDR specifications 40 Gb/s total bandwidth
- 4 independent duplex channels operating at 10Gbps, also support for 2.5Gbps, 5Gbps data rates
- 100 ohm differential impedance system
- Low Near-End Crosstalk (NEXT)
- Operating case temperature: -40 to 85°C
- All-metal housing for superior EMI performance
- Precision process control for minimization of pair-to-pair skew
- AC coupling of PECL signals
- EEPROM for cable signature & system communications
| Brand | |
|---|---|
| Brand | Legrand Group |
| General Features | |
|---|---|
| Data Transfer Rate | 40 Gbit/s |
| Maximum Distance | 22.97 ft |
| Manufacturer | Legrand Group |
| Cables | |
|---|---|
| Cable Length | 13.12 ft |
| Cable Type | Twinaxial |
| Connector Type on First End | QSFP+ Network |
| Connector on First End Details | 1 x QSFP+ Network |
| Connector Type on Second End | QSFP+ Network |
| Jacket Material | Polyvinyl Chloride (PVC) |
| American Wire Gauge | 28 AWG |
| Compliance & Certification | |
|---|---|
| Environmentally Friendly | Yes |
| Packaging & Origin | |
|---|---|
| Package Type | OEM |
