- Transmission data rate up to 25.78Gbps
- 850nm VCSEL laser
- PIN photo-detector
- Internal CDR on both transmitter and receiver channels
- Low power consumption < 1W
- Hot-pluggable SFP28 form factor
- Up to 70m on OM3 MMF and 100m on OM4 MMF
- Digital diagnostics functions are available (optional)
- Operating case temperature range: 0°C to +70°C
- 3.3V power supply voltage
- RoHS-6 compliant
| Brand | |
|---|---|
| Brand | Legrand Group |
| General Features | |
|---|---|
| Data Transfer Rate | 25.7 Gbit/s |
| Maximum Distance | 492.13 ft |
| Manufacturer | Legrand Group |
| Cables | |
|---|---|
| Fiber Optic Cable Core/Claddi | 50/125 µm |
| Cable Length | 65.62 ft |
| Cable Type | Fiber Optic |
| Fiber Category | OM3 |
| Fiber Optic Mode | Multi-mode |
| Connector Type on First End | SFP28 Network |
| Connector on First End Details | 1 x SFP28 Network |
| Connector Type on Second End | SFP28 Network |
| Jacket Type | LSZH |
| Compliance & Certification | |
|---|---|
| Environmentally Friendly | Yes |
| Packaging & Origin | |
|---|---|
| Package Type | OEM |
