This transformer converts high voltage (208V) input to low voltage (120V) output, suitable for powering low voltage AC equipment. It features a 2U rack-mount design and includes 12 NEMA 5-20R outlets. The unit includes rack mounting brackets and user manual.
- Rack-mounted mounting mode
- 2 years repair or replace warranty
- Includes Rack Mounting brackets & User Manual
- The Step-Down Transformer converts high voltage (208 or 200 VAC) output into low voltage (120 or 100 VAC) output.
- APC Step-Down Transformer
| Brand | |
|---|---|
| Brand | Schneider Electric SA |
| Power & Battery | |
|---|---|
| Output Receptacle Detail | 12 x NEMA 5-20R |
| Input Receptacle Type | NEMA L6-30P |
| Output Receptacle Type | NEMA 5-20R |
| Input Voltage | 208 V |
| Output Voltage | 120 V |
| Power Rating | 5000 VA |
| Maximum Line Current | 30 A |
| Size / Dimensions | |
|---|---|
| Form Factor | Rack-mountable |
| Mounting Location | Front |
| Rack Height | 2U |
| Mounting Preference | No Preference |
| General Features | |
|---|---|
| Manufacturer | Schneider Electric SA |
| For Country/Region | United States |
| Compliance & Certification | |
|---|---|
| Product Take Back Program | Yes |
| REACH free of SVHC | No |
| Environmentally Friendly | Yes |
