Smart-UPS™ are trusted by millions of IT professionals throughout the world to protect equipment and critical data from costly interruptions by supplying reliable, network-grade power reliably and efficiently. Available in a variety of forms factors and classes (entry level, standard and extended run), there is a model for nearly every application and budget. Standard models are the most popular UPS in the world for business servers, storage and network devices and have long been considered the benchmark for reliability and manageability. Entry level Smart-UPS models are an economical choice for small and medium businesses looking to protect small networking devices, point-of-sale (POS) equipment and entry level servers. The extended run models accept external battery packs for long runtime to power critical servers, security and communication systems through outages that could last hours.
- Energy meter - Provides actual kilowatt hours of usage for energy conscious users.
- Disconnected battery notification - Warns when a battery is not available to provide backup power.
- Cold-start capable - Provides temporary battery power when the utility power is out.
- Boost and Trim Automatic Voltage Regulation (AVR) - Gives higher application availability by correcting low and high voltage conditions without using the battery (not available on all models).
- Battery failure notification - Provides early-warning fault analysis on batteries enabling timely preventive maintenance
- Automatic self-test - Periodic battery self-test ensures early detection of a battery that needs to be replaced.
- Automatic restart of loads after UPS shutdown - Automatically starts up the connected equipment upon the return of utility power.
- Audible alarms - Provides notification of changing utility power and UPS power conditions
- Adjustable voltage-transfer points - Maximizes useful battery life by widening the input voltage window or tig
| Brand | |
|---|---|
| Brand | Schneider Electric SA |
| Power & Battery | |
|---|---|
| Number of Battery & Surge Out | 12 |
| Battery Chemistry | Lead Acid |
| Typical Battery Recharge Time | 3 Hour |
| Output Voltage | 230 V AC |
| Load Capacity (Watt) | 2700 W |
| Load Capacity (VA) | 3000 VA |
| Transfer Time | 4 ms |
| Waveform Type | Sine Wave |
| Size / Dimensions | |
|---|---|
| Form Factor | Rack-mountable |
| Rack Height | 2U |
| General Features | |
|---|---|
| Manufacturer | Schneider Electric SA |
| Compliance & Certification | |
|---|---|
| Environmentally Friendly | Yes |
