Reliable protection for industrial controls.
Continuity of process control is critical across a wide range of Industrial segments: Water/Waste Water, Biotech / Pharmaceutical, Transportation, Chemical, Food & Beverage, Semiconductor, Automotive, Renewable Energy. Equipment utilized in these segments is often subjected to harsh environments including wide temperature ranges or air characteristics with elevated moisture and salt content. APC offers a range of UPS solutions for industrial control applications including communication accessories for dry contact I/O, Modbus and network management. During a power event, whether the requirement is safe shutdown or maintaining data integrity, the APC solution provides reliable protection.
- Experience higher efficiency with lower energy cost
- Up to 8 minute runtime on full load to preserve critical data from power shortage interruptions
- 325 W load capacity - backup power for your valuable electronics
- 500 VA load capacity provides sufficient backup during power failures
- 1 batteries for better reliance and maximum dependability
- 2.50 Hour typical battery recharge time for better convenience and prolonged, productive usage
- Lead Acid battery chemistry to better suit your requirements with maximum productivity
- Hard Wire 3 wire (1PH+N+G) plug/connector type for maximum usability with added reliability
- Hard Wire 3-wire (H N + G) receptacle type offers ease of operation with maximum efficiency
- 230 V AC input voltage for optimal performance with maximum usability
| Brand | |
|---|---|
| Brand | Schneider Electric SA |
| Power & Battery | |
|---|---|
| Battery Characteristics | Maintenance-free , Spill-proof |
| Emergency Power OFF | Yes |
| Dataline Protection | DB-9 |
| Receptacle Detail | 1 x Hard Wire 3-wire (H N + G) |
| Receptacle Type | Hard Wire 3-wire (H N + G) |
| Plug/Connector Type | Hard Wire 3 wire (1PH+N+G) |
| Battery Chemistry | Lead Acid |
| Number of Batteries | 1 |
| Typical Battery Recharge Time | 2.50 Hour |
| Input Voltage | 230 V AC |
| Output Voltage | 230 V AC |
| Load Capacity (Watt) | 325 W |
| Load Capacity (VA) | 500 VA |
| Backup/Run Time (Full Load) | 8 Minute |
| Backup/Run Time (Half Load) | 24 Minute |
| Surge Energy Rating | 540 J |
| Size / Dimensions | |
|---|---|
| Form Factor | Panel Mount |
| General Features | |
|---|---|
| Hot Swappable | Yes |
| Alarm | Overload |
| Manufacturer | Schneider Electric SA |
| Thermal Dissipation | 26.38 W |
| Expansion Slots | |
|---|---|
| Total Number of Expansion Slots | 1 |
| Misc Ports | |
|---|---|
| Serial Port | Yes |
| Compliance & Certification | |
|---|---|
| Maximum Operating Temperature | 104°F (40°C) |
| Sound Emission (A-Weighted) | 55 dB(A) |
