The 4-port Amer Networks 10/100M Desktop PoE Switch provides a seamless network connection, integrating 100Mbps Fast Ethernet and 10Mbps Ethernet network capabilities. Cost saving and flexible with PoE power provision, the SD4P4U provides a PoE power injector function which is able to drive 4 IEEE 802.3af compliant powered devices. The switch also provides a simple, cost-effective, and highly reliable network connection for data as well as power.
- Total PoE power budget: 60W
- Supports networking standards IEEE 802.3i, 802.3x, 802.3af, 802.3at
- Metal Chassis Construction
- Wall and deskmount mounting
- Standard IEEE802.3af support
- 8+1 port 10/100 Switch with 4 x PoE IEEE802.3af ports & 5 x 10/100Mbps ports including uplink
| Brand | |
|---|---|
| Brand | Amer Networks |
| Power & Battery | |
|---|---|
| Power Source | Power Adapter |
| Networking & Connectivity | |
|---|---|
| Network Technology | 10/100Base-TX |
| Layer Supported | 2 |
| Ethernet Port | |
|---|---|
| Total Number of Network Ports | 9 |
| Uplink Port | Yes |
| Size / Dimensions | |
|---|---|
| Form Factor | Under Table |
| Appearance | |
|---|---|
| Modular | No |
| General Features | |
|---|---|
| Manageable | No |
| Manufacturer | Amer Networks, Inc |
| Misc Ports | |
|---|---|
| Stack Port | No |
| Port/Expansion Slot Details | 5 x Fast Ethernet Uplink |
| Printer/Scanner/Fax Specs | |
|---|---|
| Media Type Supported | Twisted Pair |
