Quad Display - Up to 4K x 4
When linked to a computer that supports Thunderbolt (or many USB4 machines) the DU4 dock can connect up to four external displays in flexible combinations of the 2x HDMI, 3x DisplayPort and 2x Thunderbolt downstream ports.
The DU4 dock will also connect up to three displays to laptops that don't support Thunderbolt.
Universal All-in-One Connectivity
The DU4 docking station provides universal compatibility and works with all Windows, Mac and Chromebook computers and laptops.
In addition to supporting up to four external displays, the dock provides ample connections for all other standard peripherals including:
- 2 x Thunderbolt 4 downstream ports (40Gbps / video output capable)
- 2 x HDMI video outputs
- 3 x DisplayPort video outputs
- 1 x USB-C 3.2 Gen 2 (10G)
- 1 x USB-A 3.2 Gen 2 (10G)
- 2 x USB-A 3.2 Gen 1 (5G)
- 2.5 Gigabit Ethernet
- Combo Headphone/Microphone Jack (384 kHz)
- SD and Micro SD Card Reader (SD 4.0 / UHS-II - 312Mbps)
Easy Deployment
Allowing all modern USB-C equipped or older USB-A computers to be connected to a minimum of two displays, this dock enables IT professionals and organisations to deploy the DU4 docking station as a single solution across all users.
The DU4 dock helps removes clutter and can power statically assigned workspaces and flexible hot desks in any organisation.
Lock slots allow the dock to be secured when used in shared workspaces.
Power Plus
The dock features a 150W power adapter featuring GaN technology for powerful and efficient operation.
As well as powering the dock and all connected peripheral devices, the dock can provide up to a huge 96W of power to the connected laptop - enough to charge all but the most power hungry machines.
- Wired connectivity technology is highly feasible, offers maximum usability
- Charging capability puts less strain on the charging port to allow prolonged usability
- Thunderbolt 4 host interface allows powerful and efficient transfer of data with maximum productivity
- Desktop PC device supported according to your requirements with maximum productivity
- 5 GB/s maximum data transfer rate for convenient, quicker exchange of data and information
- Power Delivery Pass-through feature for maximum usage productivity with added dependability
- 2.5 Gigabit Ethernet Ethernet technology for increasing efficiency with the quicker transfer and sharing of information
- Power Adapter power source type for your docking station better reliance and maximum energy dependability
- Enjoy HD quality videos on your HDTV with the HDMI port facility
- 4 USB ports offers a more refined structure and safer to use connectivity
| Brand | |
|---|---|
| Brand | Alogic |
| GPU / Graphics | |
|---|---|
| Number of Displays Supported | 4 |
| Screen / Display | |
|---|---|
| Screen Mode Supported | 4K @30Hz |
| Supported Resolutions | 7680 x 4320 |
| Power & Battery | |
|---|---|
| Charging Capability | Yes |
| Maximum Power Supply Wattage | 150 W |
| Power Source Type | Power Adapter |
| Networking & Connectivity | |
|---|---|
| Connectivity Technology | Wired |
| USB Ports | |
|---|---|
| Number of USB 3.2 Gen 1 Type- | 2 |
| Number of USB 3.2 Gen 2 Type- | 1 |
| USB Power Delivery | 96W |
| Total Number of USB Ports | 4 |
| USB Type-C | Yes |
| Number of USB Type-C Ports | 1 |
| USB Type-A | Yes |
| Number of USB Type-A Ports | 3 |
| HDMI Ports | |
|---|---|
| HDMI | Yes |
| Number of HDMI Outputs | 2 |
| Thunderbolt Ports | |
|---|---|
| Thunderbolt | Yes |
| Number of Thunderbolt 4 Ports | 3 |
| Thunderbolt Ports Quantity | 3 |
| DisplayPort | |
|---|---|
| DisplayPort | Yes |
| Number of DisplayPort Outputs | 3 |
| DisplayPort Version | 1.4 |
| Ethernet Port | |
|---|---|
| Network (RJ-45) | Yes |
| Number of RJ-45 Ports | 1 |
| Audio Ports | |
|---|---|
| Headphone/Microphone Combo Po | Yes |
| Card Reader | |
|---|---|
| Memory Card Reader | Yes |
| Memory Card Supported | microSD |
| Appearance | |
|---|---|
| Color | Not Specified |
| General Features | |
|---|---|
| Maximum Data Transfer Rate | 5 GB/s |
| Manufacturer | Alogic |
| Misc Ports | |
|---|---|
| Host Interface | Thunderbolt 4 |
| Cables | |
|---|---|
| Cable Length | 2.62 ft |
| Brand | Alogic |
| MPN | TB4DU4 |
| Unit Count | 1 Units |
| Return Policy | This product is eligible for 30-day returns. See our return policy for details. |
