Industrial cellular router ICR-2441 is designed for wireless communication to enable the connection of IP or serial devices to a cellular network. Industrial M2M and IoT applications include kiosks, industrial PCs, HMIs, traffic controllers, meters, UPS systems, and much more. The peak downlink data rate for LTE Cat.4 is approximately 150 Mbps. Also in the uplink, LTE Cat.4 provides a peak data rate of 50 Mbps.
The router is equipped with two independently configurable Ethernet ports (LAN or WAN), 1� serial port RS232, 1� RS485, and digital I/O connectivity (1� DI, 1� DO). Optional built-in WiFi 802.11 ac/a/b/g/n with AP, Client, Multirole modes or optional integrated GNSS functionality is available.
The router supports VPN tunnel creation using various protocols to ensure safe communications. The router provides diagnostic functions which include automatic monitoring of the wireless and wired connections, automatic restart in case of connection losses, and a hardware watchdog that monitors the router status.
The router is based on the ICR-OS operation system. Open Linux platform enables wide possibilities of programming customer SW applications in Python and C/C++. The router supports uploading of Router Apps that would extend standard firmware functionalities. The existing app library ready for free download by customers contains already developed software apps to enhance specific router functionality including industrial protocol conversions, support of IoT platforms such as MS Azure, Cumulocity and a lot more.
