The Server Technology® PRO2 Smart PDU provides local LED input current monitoring, allowing IT personnel to determine safe levels of loading on a per-phase basis while installing equipment into the rack/cabinet. The integral PIPS® technology provides billing-grade accurate measurement of current, voltage, active power, apparent power, power factor, crest factor, and accumulated energy at the input. These power data points, along with temperature and humidity measurements (provided via optional probes), are accessible through the built-in Web and CLI interfaces as well as through SNMP. The PRO2 Smart "Primary" PDU can be connected to as many as three (with optional module) PRO2 Smart "Link" PDU to extend the network access to the redundant or secondary power feed without the risks of a daisy chain linking configuration.
- Includes standard button mounts along with provisions for custom mounting brackets.
- FLEXIBLE MOUNTING:
- HIGH TEMPERATURE RATING:
- This product has been tested and approved for safe and reliable operation in 60 °C data center environments.
- PRO2 receptacles have high retention and are compatible with P-Lock type power cords.
- HIGH RETENTION LOCKING OUTLETS:
- ALTERNATING-PHASE OUTLETS:
- Evenly distributes multiple phases of power to each outlet for simplified load balancing, reduced cord lengths, and better airflow.
- This PDU meets the UL and IEC 62368-1 requirement for branch circuit protection through UL 489 rated magnetic-hydraulic circuit breakers or UL 248 fuses.
- BRANCH CIRCUIT PROTECTION:
- BRANCH CURRENT MONITORING:
- Monitors current at each breaker branch and provides SNMP-based alerts and emails on high usage that risks a tripped circuit.
- PIPS® (Per Inlet Power Sensing) Monitors Current Load (A), Voltage (V), Power (W), Apparent Power (VA), Crest Factor, Power Factor, & Energy per inlet.
- PER-INLET PO
| Brand | |
|---|---|
| Brand | Legrand Group |
| Power & Battery | |
|---|---|
| Power Rating (Watt) | 8600 W |
| PDU Type | Monitored |
| Phase | Three Phase |
| Circuit Breaker | Yes |
| Receptacle Detail | 18 x CX |
| Receptacle Type | CX |
| Plug/Connector Type | NEMA L15-30P |
| Locking Receptacles | P-Lock |
| Input Voltage | 230 V AC |
| Output Voltage | 208 V AC |
| Input Current | 30 A |
| Ethernet Port | |
|---|---|
| Network (RJ-45) | Yes |
| Size / Dimensions | |
|---|---|
| Mount Type | Cabinet-mountable |
| General Features | |
|---|---|
| Protection Type | Circuit Protection |
| Manufacturer | Legrand Group |
| Compliance & Certification | |
|---|---|
| Maximum Operating Temperature | 140°F (60°C) |
| Maximum Storage Temperature | 185°F (85°C) |
| Minimum Storage Temperature | -40°F (-40°C) |
| Maximum Operating Humidity | 90% |
| Minimum Operating Humidity | 8% |
