1+km transmission Range
O1-5G adopts of internal power amplifier and 9dBi directional antenna to provide an efficient way to pick up and maintain a stable signal for a wireless network up to 1km.
Flexible power supply method enable it easy to deployment
O1-5G supports 12V 1A Passive PoE and 12V 1A DC power supply option. It helps the engineer to deploy the device flexiblely.
Auto-bridge technology enable it to easy setup
O1-5G supports auto-bridge technology, It enables the CPE or basestation in factory default settings to connect to each other automaticaly after the device is powered on. It is very useful for the person who is not familiar with network knowledge, especially for CCTV surveillance transmission application.
Easy to Setup and Manage
O1-5G comes with a centralized management software that helps users easily to manage all the devices in the network from a single PC-CPE Assistant.
Professional Outdoor Design
Equipped with IP65 waterproof enclouse and high quality hardware design, OS3 can work in various weather conditions, such as sunshine, rainfall or extremely low/high temperature environment
Multiple Application Scenarios | PtP Connection For CCTV Transmission
One work as AP mode and another work as Station mode to create a long distance wrieless connecton for video surveillance
PtP Connection For internet sharings
One work as AP mode and another work as Station mode to create a long distance wrieless connecton for internet sharing between buildings or neighbors
Wireless Internet Access for Private ISP
Wirelessly connect to Private ISP tower signal to share Internet to local wireless and wired network.
- 5GHz 11AC 867Mbps
- 9dbi directional antenna
- One Fast Ethernet Port
- IP65 waterproof enclosure
- 12V 1A DC/12V 1A Passive PoE supported
| Brand | |
|---|---|
| Brand | Tenda Technology Inc |
| Power & Battery | |
|---|---|
| Power Consumption | 4.70 W |
| Networking & Connectivity | |
|---|---|
| Wireless Transmission Speed | 867 Mbit/s |
| Frequency Band | 5 GHz |
| Outdoor Antenna Range | 3280.8 ft |
| Ethernet Port | |
|---|---|
| Number of Network (RJ-45) Por | 1 |
| PoE PD Port | Yes |
| Size / Dimensions | |
|---|---|
| Form Factor | Wall Mountable |
| Security | |
|---|---|
| Data Encryption | Yes |
| Encryption Standard | WPA |
| General Features | |
|---|---|
| Indoor/Outdoor | Outdoor |
| Manufacturer | Tenda Technology Inc |
| Compliance & Certification | |
|---|---|
| Ingress Protection (IP) Rating | IP65 |
