Artistic Immersion, Overwhelming Captivation | Daisy Chain Capability
By using this daisy-chained network feature, you can execute commands such as controlling, monitoring and even updating firmware.
Real-Time LG ConnectedCare
Maintenance is easy and fast with the optional LG ConnectedCare service, a cloud service solution provided by LG. It remotely manages the status of displays in client workplaces for fault diagnosis and remote-control services, enabling the stable operation of clients' businesses.
Ultra Narrow Bezel
The 3.5mm ultra narrow bezel size creates immersive and seamless viewing experiences on assembled video wall screens.
Easy Color Adjustment
Depending on the content, the color temperature of the display can be easily adjusted in increments of 100K using a remote control.
Image Gap Reduction
The VL5PJ includes an image improvement algorithm that can reduce image gaps among tiled displays when playing back videos. Objects located on the bezel boundaries are adjusted for a seamless viewing experience.
High Performance and Great Scalability
Thanks to its built-in SoC and webOS smart signage platform, the VL5PJ can execute several tasks at once while providing smooth content playback without the need for a media player. As webOS supports HTML5 as a web-based platform and offers SDK (Software Development Kit), it is even easier for SIs to build and optimize their web apps.
- Brightness(Typ.) : 500 nit
- Bezel : 2.25 mm (T/L), 1.25 mm (B/R)
- Depth : 89.7 mm
- Interface : HDMI/ DP/ DVI-D/ USB/ RS232C/ RJ45/ Audio/ IR
| Brand | |
|---|---|
| Brand | LG Electronics |
| GPU / Graphics | |
|---|---|
| Number of Screens | 4 |
| Memory / RAM | |
|---|---|
| Standard Memory | 8 GB |
| Screen / Display | |
|---|---|
| Native Contrast Ratio | 000:1 , 1 |
| Dynamic Contrast Ratio | 000:1 , 500 |
| Video Wall Configuration | 2x2 |
| Screen Size Class | 49" |
| Viewable Screen Size | 49" |
| Video Wall Compatible | Yes |
| Display Resolution | 1920 x 1080 |
| Display Screen Type | LCD |
| Aspect Ratio | 16:9 |
| Panel Technology | In-plane Switching (IPS) Technology |
| Brightness | 500 Nit |
| Response Time | 8 ms |
| Color Gamut | 72% NTSC |
| Color Depth | 10-bit |
| Power & Battery | |
|---|---|
| Power Consumption (DPM) | 0.5W |
| Input Voltage | 230 V AC |
| Off-Mode Power Consumption | 500 mW |
| Networking & Connectivity | |
|---|---|
| Ethernet | Yes |
| USB Ports | |
|---|---|
| USB | Yes |
| HDMI Ports | |
|---|---|
| HDMI | Yes |
| Number of HDMI Inputs | 2 |
| DisplayPort | |
|---|---|
| DisplayPort | Yes |
| DisplayPort Output | Yes |
| Number of DisplayPorts | 2 |
| Number of DisplayPort Outputs | 1 |
| Ethernet Port | |
|---|---|
| Number of Network (RJ-45) Por | 1 |
| Audio Ports | |
|---|---|
| Number of Audio Line Out | 1 |
| Size / Dimensions | |
|---|---|
| VESA Mount Standard | 600 x 400 |
| Mount Type | Surface Mount |
| Orientation | Landscape/Portrait |
| Bezel Width | 0.14" |
| Bezel Width (Top) | 88.6 mil |
| Bezel Width (Bottom) | 49.2 mil |
| Bezel Width (Left) | 88.6 mil |
| Bezel Width (Right) | 49.2 mil |
| Appearance | |
|---|---|
| Bezel Color | Black |
| General Features | |
|---|---|
| Operation Hours | 24 Hours/7 Days |
| Maximum Heat Generation | 540.2 kJ |
| Manufacturer | LG Electronics |
| Maximum LED Life | 6.8 Year |
| Video Ports | |
|---|---|
| DVI | Yes |
| Number of DVI-D Ports | 1 |
| Misc Ports | |
|---|---|
| Serial | Yes |
| RS-232C Input | Yes |
| RS-232C Output | Yes |
| Printer/Scanner/Fax Specs | |
|---|---|
| Scan Format | 1080p |
| Compliance & Certification | |
|---|---|
| Maximum Operating Temperature | 104°F (40°C) |
| Minimum Operating Temperature | 32°F (0°C) |
| Maximum Operating Humidity | 80% |
| Minimum Operating Humidity | 10% |
| Energy Star | Yes |
| Ingress Protection (IP) Rating | IP5X |
| Energy Efficiency Compliance | Energy-related Products Directive (ErP) |
