High Visibility Under Bright Environments
With a brightness of 1,500 nits, 22XE1J boasts high visibility in bright environments. In addition, its clear visibility can deliver a variety of information even to those wearing polarized sunglasses.
21.5 inches of Versatile Screen Size
The small and light size of 21.5 inches allows for flexible use in various spaces. In particular, you can install the display in various way allowing for high utilization for small-medium businesses (SMB) to large businesses.
Secured Protection with IP56 Design
The display is sealed with IP56 design for reliable operation. It's designed to be not only waterproof but also weatherproof against the damaging effects of the sun, rain, snow, dust and wind, which is an essential feature for outdoor application.
Wide Operating Temperature Range
22XE1J can be used under a wide range of operating temperatures which results in fewer constraints for outdoor installation.
Conformal Coating
Conformal Coating improves reliability of the circuit board, power board by protecting it against dust, iron powder, humidity, etc.
Smart Brightness Control
The screen brightness is automatically adjusted depending on the ambient light. The brightness is increased in light for better visibility, while it is decreased in darkness for efficient power management.
High Performance with webOS
Quad Core SoC can execute several tasks at the same time without a separate media player. In addition, webOS 4.1 platform enhances user convenience with intuitive UI and simple app development tools.
Easy Content Distribution
& SW Update
22XE1J features embedded Wi-Fi, Bluetooth, Beacon making it easy to distribute content wirelessly and update Firmware. In particular, using Beacon and BLE (Bluetooth Low Energy), shop manager can do various promotional activities, such as providing promotional coupons or product information to visitor in real time.
Web Monitoring (Control Manager)
This is a web-based monitoring solution, which provides a ease of control for the user. It enables users to have full access anywhere, anytime from their mobile phone & PC as long as they're connected to a network while having access to both current and past data. It allows users to monitor the unit, make any adjustments and control it remotely in real-time.
LG's Simple Advertisement Helper, Promota
Using LG's Promota application, downloadable on a mobile device, you can easily create your own display contents. With Promota, you can add text and images to create an online profile for your business as well as deliver information such as event news, seasonal menus, promotions, and even more to your customers while recommending easy-to-use templates relevant to your industry.
Real-time LG ConnectedCare Service
Maintenance is easy and fast with the optional LG ConnectedCare service, a cloud service solution provided by LG. It remotely manages the status of displays in client workplaces for fault diagnosis and remote-control services, supporting the stable operation of clients' businesses.
- Brightness (Typ, w/ Glass) : 1,500 nits
- IP56 Rated
- 21.5" of Versatile Display Size
- Wide Operating Temperature Range
- webOS™ Smart Platform
- Web-based Monitoring Solution
| Brand | |
|---|---|
| Brand | LG Electronics |
| Screen / Display | |
|---|---|
| Native Contrast Ratio | 000:1 , 1 |
| Dynamic Contrast Ratio | 000:1 , 800 |
| On Screen Display (OSD) Langu | Turkish |
| Image Sticking Minimization ( | Yes |
| Viewable Screen Size | 22" |
| Multi-touch Screen | No |
| Backlight Technology | Edge LED |
| Display Resolution | 1920 x 1080 |
| Aspect Ratio | 16:9 |
| Panel Technology | IPS Technology with Advanced Hyper Viewing Angle (AHVA) |
| Brightness | 1500 Nit |
| Response Time | 25 ms |
| Standard Refresh Rate | 60 Hz |
| Color Gamut | 72% NTSC |
| Horizontal Viewing Angle | 178° |
| Vertical Viewing Angle | 178° |
| Color Depth | 8-bit |
| Power & Battery | |
|---|---|
| Power Consumption (DPM) | Less Than 0.5W |
| Input Voltage | 230 V AC |
| Off-Mode Power Consumption | 500 mW |
| Power Consumption | 115 W |
| Networking & Connectivity | |
|---|---|
| Infrared Output | No |
| Wireless LAN | Yes |
| Bluetooth | No |
| USB Ports | |
|---|---|
| USB Type-C | No |
| Number of USB 2.0 Ports | 1 |
| HDMI Ports | |
|---|---|
| Number of HDMI Inputs | 2 |
| DisplayPort | |
|---|---|
| DisplayPort In | No |
| DisplayPort Output | No |
| Ethernet Port | |
|---|---|
| Number of Network (RJ-45) Por | 1 |
| Network (RJ-45) | No |
| Audio Ports | |
|---|---|
| Audio Line Out | No |
| Audio Line In | No |
| Audio | |
|---|---|
| Speakers | No |
| RMS Output Power | 20 W |
| Software & Licensing | |
|---|---|
| Embedded CMS | Local Contents Scheduling |
| Compatible Software | SuperSign Control+ |
| Size / Dimensions | |
|---|---|
| Front Glass Thickness | 78.7 mil |
| VESA Mount Standard | 100 x 100 |
| Orientation | Landscape/Portrait |
| Bezel Width (Top) | 0.94" |
| Bezel Width (Bottom) | 0.94" |
| Bezel Width (Left) | 1.51" |
| Bezel Width (Right) | 1.51" |
| Appearance | |
|---|---|
| Bezel Color | Black |
| Surface Hardness | 3H |
| Security | |
|---|---|
| HDCP Version | 1.4/2.2 |
| General Features | |
|---|---|
| Operation Hours | 24 Hours/7 Days |
| Maximum Heat Generation | 414.6 kJ |
| Manufacturer | LG Electronics |
| Maximum LED Life | 8 Year |
| Video Ports | |
|---|---|
| DVI-D In | No |
| Misc Ports | |
|---|---|
| RS-232C Input | Yes |
| Compliance & Certification | |
|---|---|
| Maximum Operating Temperature | 122°F (50°C) |
| Minimum Operating Temperature | -22°F (-30°C) |
| Maximum Operating Humidity | 100% |
| Minimum Operating Humidity | 5% |
| TAA Compliant | No |
| Energy Star | No |
| Environmentally Friendly | Yes |
| Environmental Certification | ErP |
| Ingress Protection (IP) Rating | IP56 |
| Energy Efficiency Compliance | Energy-related Products Directive (ErP) |
| Packaging & Origin | |
|---|---|
| Country of Assembly | South Korea |
