Intellinet Network Solutions 5-Port Gigabit Office Switch, Desktop, Metal Housing

19.40 19.40
19.40

19.40 / Units
  • Brand
  • Weight (Approximate)
  • Height
  • Product Name
  • Number of Network (RJ-45) Por
  • Marketing Information
  • Brand Name
  • Manufacturer Part Number
  • Width
  • Redundant Power Supply Suppor
  • LRE Port
  • Token Ring Port
  • Bypass
  • Network Technology
  • Manageable
  • Modular
  • USB
  • Total Number of Network Ports
  • PoE (RJ-45) Port
  • Management Port
  • Uplink Port
  • Stack Port
  • Port/Expansion Slot Details
  • Twisted Pair Cable Standard
  • Form Factor
  • Product Color
  • Color Family
  • Length
  • Ethernet Technology
  • Layer Supported
  • Media Type Supported
  • Environmentally Friendly
  • Post-consumer-waste%
  • Certifications & Standards
  • Recycled
  • Packaged Quantity
  • Country of Origin
  • Package Contents
  • Limited Warranty
  • Assembly Required
  • Manufacturer
  • Product Type
  • Product Model
  • Manufacturer Website Address
  • Power Source
  • Power Consumption
This product is eligible for 30-day returns. See our return policy for details. Terms and Conditions
Shipping: 1-6 Business Days

Easy to install, with auto-learning capabilities

The Intellinet Network Solutions Gigabit Ethernet Switch is perfect for the home or small office, delivering top speeds to the desktop to satisfy your demanding network needs.

High-Speed Performance

This desktop switch includes five Gigabit Ethernet ports, providing you with high performance on your network to handle quick transfer speeds that support disk mirroring, data backup, graphics image file transfers and other bandwidth-intensive applications.

Auto Features

This network LAN switch includes many automatic features that make it easy to use. No configuration is required, so installation is Plug and Play and hassle free. Auto-MDI/MDI-X crossover on all ports eliminates the need for any crossover cables. Each of the five ports on this network LAN switch automatically senses the link speed of the connected network device and adjusts to 10, 100 or 1000 Mbps for compatibility and maximum performance.

Reliable Operation

The Intellinet Network Solutions Gigabit Ethernet Switch supports flow control when operating in half duplex mode and IEEE 802.3ab in full duplex mode to ensure that data transfer and network connectivity run smoothly and uninterrupted. In conjunction with the broadcast storm control and the store and forward switching method, flow control further ensures that your connections remain active even under extremely busy conditions.

  • 10/100/1000 auto-sensing Auto MDI-X ports to automatically detect optimal network speeds
  • High performance, half and full duplex, with zero packet loss
  • Full flow control support provides optimum performance
  • Auto-learning of network configuration
  • Supports up to 8192 MAC address entries
Brand
Brand IC INTRACOM
Power & Battery
Redundant Power Supply Suppor No
Power Source Power Adapter
Power Consumption 1.60 W
Networking & Connectivity
Token Ring Port No
Network Technology 10/100/1000Base-T
Layer Supported 2
USB Ports
USB No
Ethernet Port
Number of Network (RJ-45) Por 5
LRE Port No
Total Number of Network Ports 5
PoE (RJ-45) Port No
Uplink Port No
Size / Dimensions
Form Factor Desktop
Appearance
Modular No
General Features
Manageable No
Manufacturer IC INTRACOM
Misc Ports
Management Port No
Stack Port No
Port/Expansion Slot Details 5 x Gigabit Ethernet Network
Printer/Scanner/Fax Specs
Media Type Supported Twisted Pair
Cables
Twisted Pair Cable Standard Category 5e
Compliance & Certification
Environmentally Friendly Yes
Recycled No
Miscellaneous
Bypass No
Assembly Required No
Intellinet Network Solutions 5-Port Gigabit Office Switch, Desktop, Metal Housing - IEEE 802.3az (Energy Efficient Ethernet)
