Eaton Metered Input ePDUs provide remote monitoring of the current draw of individual sections via network communication. This capability, combined with state-of-the-art software allows you to aggregate the information from many ePDUs in one location. A local display is also available for phase balancing and for easy start-up and provisioning of servers. New ePDU G3 Metered Input models feature best-in-class technologies, including ±1% billing grade accuracy, an advanced LCD pixel display, a hot-swap meter and the ability to daisy chain four ePDUs to share the same network connection and IP address.
- UL Listed (UL489) branch circuit breakers meet UL60950-1 Edition requirements
- Reading available via Ethernet connection over a network
- Clearly labeled circuits simplify load balancing
- Easy read digital ammeter reduces local monitoring time
- High density units support up to 25 1U/2U servers or three blade server chassis
- New ePDU G3 models feature ±1% billing grade accuracy, an advanced LCD pixel display, a hot-swap meter and the ability to daisy chain four ePDUs to share the same network connection and IP address
| Brand | |
|---|---|
| Brand | Eaton Corporation |
| Power & Battery | |
|---|---|
| Power Rating (Watt) | 8600 W |
| Receptacle Detail | 33 x AC Power |
| Receptacle Type | AC Power |
| Plug/Connector Type | NEMA L21-30P |
| Input Current | 24 A |
| Size / Dimensions | |
|---|---|
| Mount Type | Rack-mountable |
| Rack Height | 38U |
| General Features | |
|---|---|
| Manufacturer | Eaton Corporation |
