Backup Battery Module Gives Your Compatible Eaton UPS System Extended Runtime
The valve regulated lead acid 9PXEBM240RT offers extended battery runtime when used in conjunction with Eaton's 9PX8KHW, 9PX8KTF5, 9PX8K, 9PX11KHW, 9PX11KTF11, 9PX11KTF11M, 9PX11KTF5 and 9PX11K 9PX UPS systems. It can also be daisy-chained for a maximum of five matching battery packs (or up to 12 with the optional SC240RT supercharger module, sold separately) to deliver even longer extended-run operation. Heavy-gauge cabling with high-current DC connectors is included for safe, simple installation.
Versatile Installation Options
You can mount the 9PXEBM240RT in 3U of space in an EIA-standard 19-inch rack using the included 4-post rail kit. You can also adapt it for tower installation using the included support stands.
- Daisy-chain connector supports additional battery packs for even longer runtime
- Includes heavy-gauge battery cabling with high-current 240V DC connectors
- Connects to select expandable Eaton 9PX UPS systems to add critical runtime
| Brand | |
|---|---|
| Brand | Eaton Corporation |
| Power & Battery | |
|---|---|
| Battery Chemistry | Lead Acid |
| Output Voltage | 240 V DC |
| Size / Dimensions | |
|---|---|
| Form Factor | Tower/Rack Mountable |
| Rack Height | 3U |
| General Features | |
|---|---|
| Manufacturer | Eaton Corporation |
