Live Stream Media over IP Extend AV signals as far as your network reaches.
Standardized Protocols
This media decoder is fitted with standardized and disclosure protocols, allowing it to cooperate with our H.264 encoder. With this decoder and matching encoder, you can deliver AV signals over your IP network. Compatible with a Diversified Network, the decoder supports multiple media transmission methods. Additionally, it negotiates with the encoder to select the most suitable mode to obtain media. All of this enables the decoder to adapt itself automatically to most networks.
Advanced Media Codec
The decoder features H.264 video compressing technology. This allows it to decode video content with visually lossless quality without consuming too much bandwidth. On top of that, the encoder supports AAC audio encoding so a high-quality audio signal can be transmitted using low bandwidth.
Optimized Control Methods
Setting up this decoder is simple. To pair the decoder, the user only needs to configure the IP address of the encoder. Then, the decoder will negotiate with the encoder to obtain the media stream. Furthermore, this decoder offers two controlling approaches: web UI and Telnet API. The web UI enables the user to control the system through a common browser. The Telnet API allows the devices to be controlled by a third-party system.
- Designed to work with matching encoder
- Supports static IP, DHCP and auto IP
- Two power modes: 12 V DC and PoE
- Supports resolutions up to 1920 x 1200 @ 60 Hz and 3840 x 2160 @ 30 Hz
- Standards-based H.264/MPEG-4 AVC video compression
- Receives TS data with unicast or multicast method
| Brand | |
|---|---|
| Brand | Black Box Corporation |
| Screen / Display | |
|---|---|
| Maximum Resolution | 3840 x 2160 |
| HDMI Ports | |
|---|---|
| HDMI | Yes |
| Ethernet Port | |
|---|---|
| Network (RJ-45) | Yes |
| Audio Ports | |
|---|---|
| Audio Line Out | Yes |
| General Features | |
|---|---|
| Functions | Video Streaming |
| Video Formats | TS |
| Manufacturer | Black Box Corporation |
| Compliance & Certification | |
|---|---|
| Environmentally Friendly | Yes |
