Developed for compliance.
NIAP PP4.0, TAA, and Common Criteria compliant for government and military secure environments. Meets stringent Red/Black requirements of CNSSAM-CTTA calling for 60 dB isolation for digital signaling detailed in the committee's TEMPEST/01-13, Tables 2 and 6.
Choose a solution with enhanced security.
To enhance security of the Secure KVM, audio, HDMI and remote control ports are blocked leaving existing electronics in place while improving isolation
Protect your network with highest level isolation.
IsoClave Red/Black Secure KVMs feature integrated cables with higher isolation. These elevated levels meet stringent analog and digital signal isolation requirements.
Ensure compatible cable are used out-of-the-box.
For a secure deployment, isolating host cables with ferrite chokes are preinstalled into tamper-resistant brackets on the back of the SKVM to prevent the use of incompatible cables.
Optimize operator awareness.
Reduce operator errors with panel channel identification and colorized first two ports. Customizable port coloring and naming on the front panel includes preprogrammed colors on ports 1 and 2 (port 1 is green, port 2 is red).
Advanced security measures.
Anti-tamper label and packaging thwarts unauthorized access. Always-on, battery-backed, active anti-tamper circuit protects the unit from a breach while in transit and after deployment.
Convenient compatibility.
Platform is plug and play, with fully populated cable connections requiring no assembly, and is compatible with the optional Belkin SKVM Remote Control with Integrated Keyboard, Work Surface and Under Desk Mounts.
- Designed to meet requirements for red/black isolation between enclaves specified in CNSSAM TEMPEST/01-13, Table 2 and Table 6, 60dB of isolation for digital signaling.
- Configured for the latest Common Criteria and NIAP cybersecurity standard: NIAP Protection Profile for Peripheral Sharing Devices 4.0.
- Secure and ready to deploy platform: Preinstalled isolating host cables enable efficient deployment, while providing the highest level of isolation in any commercial SKVM.
- Situational awareness: Convenient preconfigured port coloring with the option to change the color scheme, ensures front panel facilitates channel identification, reducing operator errors (channel 1 = green, channel 2 = red).
- Innovations for optimal user experience: Compatible with the Belkin SKVM Remote with Integrated USB Keyboard, delivering the ultimate solution for decluttering the desk while enhancing the operator's awareness of the security domain they're working in.
- Designed for use on government and military networks.
- Tamper-proof syst
| Brand | |
|---|---|
| Brand | Belkin International |
| GPU / Graphics | |
|---|---|
| Graphic Mode | 4K |
| Power & Battery | |
|---|---|
| Input Voltage Range | 12VDC |
| Input Current | 2.50 A |
| Networking & Connectivity | |
|---|---|
| Connectivity Technology | Wired |
| USB Ports | |
|---|---|
| USB | Yes |
| Number of USB Ports | 2 |
| DisplayPort | |
|---|---|
| DisplayPort | Yes |
| Number of DisplayPorts | 1 |
| Camera / Webcam | |
|---|---|
| Maximum Video Resolution | 3840 x 2160 |
| Software & Licensing | |
|---|---|
| Number of Local Users Support | 1 |
| Size / Dimensions | |
|---|---|
| Form Factor | Under Table |
| General Features | |
|---|---|
| Manufacturer | Belkin International, Inc |
| Device Type | Secure KVM |
| Compliance & Certification | |
|---|---|
| TAA Compliant | Yes |
