Axiom offers a full line of efficient & cost effective cabling solutions for your networking project. We use only the finest components and the latest construction technologies to optimize cable performance and ensure compliance to industry specifications for each cable and its designated application. We offer a variety of solutions including fiber, infiniband, antenna & stacking cables. Whether you're upgrading components or installing a brand new network, you'll receive the highest quality connectivity products, a Lifetime Warranty and free technical support.
- Multimode Duplex Fiber Optic Cable 50/125, OM3, Aqua
- 10 Gigabit Transfers Up To 300 Meters Using 850nm VCSEL Source
- (2) LC/UPC Connectors Each Side
- All Connectors Have Ceramic Ferrules
- Duplex Clips Both Sides
- Bend Insensitive
- Bending radius 10mm
- PVC (OFNR) Rated Aqua Jacket With Corning Glass
- Jacket OD: 2.0mm
- Typical Return Loss: -25
- Maximum Connector Loss: 0.50 dB
- Typical Connector Loss: 0.30 dB
- Long Term Tensile Strength: 150n
- Long Term Crush Resistance: 200n/100mm
- Operating Temperature: -40° C To +70° C
- Color: Aqua
| Brand | |
|---|---|
| Brand | Axiom Memory Solutions |
| Size / Dimensions | |
|---|---|
| Outer Diameter | 78.7 mil |
| General Features | |
|---|---|
| Data Transfer Rate | 10 Gbit/s |
| Manufacturer | Axiom Memory Solutions |
| Cables | |
|---|---|
| Fiber Optic Cable Core/Claddi | 50/125 µm |
| Cable Length | 3.28 ft |
| Cable Type | Fiber Optic |
| Fiber Type | Duplex |
| Fiber Category | OM3 |
| Fiber Optic Mode | Multi-mode |
| Connector Type on First End | LC Network |
| Connector on First End Details | 2 � LC/UPC Network |
| Connector Type on Second End | LC Network |
| Jacket Material | Polyvinyl Chloride (PVC) |
| Jacket Type | OFNR |
| Jacket Color | Aqua |
