ROG Astral GeForce RTX™ 5090 32GB GDDR7
ROG Astral GeForce RTX™ 5090 32GB GDDR7 - the first ROG quad-fan graphics card delivering unprecedented airflow and air pressure for optimal cooling performance
- AI Performance: 3394 AI TOPS
- Powered by the NVIDIA Blackwell architecture and DLSS 4
- OC mode: 2467 MHz (OC mode)/ 2437 MHz (Default mode)
- Quad-fan design boosts air flow and pressure by up to 20%
- Patented vapor chamber with milled heat spreader for lower GPU temperatures
- Phase-change GPU thermal pad ensures optimal heat transfer, lowering GPU temperatures for enhanced performance and reliability
- 3.8-slot design: massive heatsink and fin array optimized for airflow from the four Axial-tech fans
- Secure GPU protection with GPU Guard technology securing four corners of the GPU and GPU bracket ensures stable mounting.
- Full metal diecast shroud, frame backplate, and rear I/O bracket brace the PCB for rigidity.
- Powerful 80-amp MOSFETs help ensure enhanced performance, stability and higher overclocking potential
- Protective PCB coating guards against moisture, dust, and extreme temperatures.
- Auto-Extreme manufacturing process for precision and reliability
- GPU Tweak III software provides intuitive performance tweaking, advanced thermal controls and system monitoring
ROG Astral GeForce RTX™ 5090 | The Final Frontier
The new ROG Astral family was inspired by the limitless expanse and beauty of the cosmos, and it is a testament to an unending dedication to exploring and defining new frontiers. In that spirit, the ROG Astral GeForce RTX 5090 introduces ROG's first quad-fan graphics card, coupled with a patented vapor chamber, increased heatsink fin density, a phase-change GPU thermal pad, towering default clock speeds, boosted power delivery, and more. These premium innovations - amplified by an eye-catching die-cast frame and metal GPU bracket - combine to deliver absolute performance that can handle even the most demanding gaming scenarios.
NVIDIA Blackwell Architecture The Ultimate Platform for Gamers and Creators
Fifth-Gen Tensor Cores
Max AI performance with FP4 and DLSS 4
New Streaming Multiprocessors
Optimized for neural shaders
Fourth-Gen Ray Tracing Cores
Built for Mega Geometry
- Cost-efficient NVIDIA GeForce provides effective Blu-ray playback acceleration and great gaming experience
- OpenGL 4.6 API support for better handling of numerous graphic tasks with ease and convenience
- PCI Express 5.0 x16 host interface for reliable data transfer and enhanced performance
- With GDDR7 memory technology get efficient data transfer rate and enhanced computer's performance
- HDMI interface allows you to connect to a variety of HD devices including gaming consoles, Blu-ray players, laptop PCs, digital cameras and many others for the ultimate true high-definition display
- Plug-in Card form factor for added reliability and dependability
- Comes in 3" height for maximum productivity and easy carrying
- Comes in 5.9" width for better reliance and maximum efficiency
- Built-in 32 GB memory for a crisp and detail display
- Loaded with a power-efficient fan to dissipate heat and as a result, you get enduring usability
| Brand | |
|---|---|
| Brand | ASUS Computer International |
| GPU / Graphics | |
|---|---|
| GPU Boost Clock | 2.47 GHz |
| CUDA Cores | 21760 |
| Bus Width | 512 bit |
| API Supported | OpenGL 4.6 |
| Number of Monitors Supported | 4 |
| Memory / RAM | |
|---|---|
| Standard Memory | 32 GB |
| Memory Technology | GDDR7 |
| Memory Speed | 3.50 GB/s |
| Screen / Display | |
|---|---|
| Maximum Digital Display Resol | 7680 x 4320 |
| Power & Battery | |
|---|---|
| Power Supply Wattage | 1000 W |
| Power Connector | 1x 16-pin |
| HDMI Ports | |
|---|---|
| HDMI | Yes |
| Number of HDMI Outputs | 2 |
| DisplayPort | |
|---|---|
| DisplayPort | Yes |
| Number of DisplayPort Outputs | 3 |
| Size / Dimensions | |
|---|---|
| Form Factor | Plug-in Card |
| Slot Space Required | Quad |
| General Features | |
|---|---|
| Chipset Manufacturer | NVIDIA |
| Chipset Model | RTX 5090 |
| Chipset Line | GeForce |
| Chipset Series | RTX |
| AI-powered | Yes |
| Cooler Type | Fan Cooler |
| Manufacturer | ASUS Computer International |
| Misc Ports | |
|---|---|
| Host Interface | PCI Express 5.0 x16 |
